XD2200
XD2200 is a 125°C low-smoke halogen-free flame-retardant polyolefin wire compound — colorable, FT2 rated, compliant with the latest RoHS and REACH requirements.
Red cable compound pellet sample
01 / 02Material — LSZH cross-linkable polyolefin (XLPE/XLPO) wire compound
Overview
XD2200 is a 125°C halogen-free flame-retardant wire and cable compound, colorable, built on a polyolefin base with inorganic flame retardants, antioxidants and lubricants, internally mixed, plasticized and pelletized. It is used in volume for wire and cable insulation and jackets.
The product has passed environmental testing and complies with the latest RoHS and REACH requirements. The 125°C XLPE family it belongs to passes UL 94 V-0 style burn testing, withstands −40°C cold, and serves automotive wire, building and installation wire, electronic wire, thin-wall vehicle wire, and power, control, marine and signal cable.
Packaging & Storage
Supplied in aluminum-plastic bags with kraft paper lining, 25 kg net per bag. Store in a dry, well-ventilated warehouse.
- Product family
- Materials
- Reference
- XD2200
- Applications
- 5 documented
- Published data
- 9 rows
Grade qualification
Validate the grade against the cable, process and target standard
Published properties establish the review baseline. Cable construction, processing conditions and a line trial complete the grade decision.
- 01
Define the duty profile
Confirm cable construction, operating temperature, flame class and environmental requirements.
- 02
Review the published data
Match requirements, typical values and test methods to the finished-cable target.
- 03
Run a controlled line trial
Set drying, temperature, screw and irradiation conditions from the grade processing card.
- 04
Approve the production window
Record surface, dimensions, mechanical results and finished-cable tests before volume production.
Inquiry input
Send these four details
- 01Cable construction
- 02Target standard
- 03Color and quantity
- 04Extrusion line details
Technical data
Typical Properties
Review requirement, typical production value and test method together. The official TDS defines the binding supply specification.
- Density
- 1.45 g/cm³
- Tensile strength
- 10.5 MPa
- Elongation at break
- 200 %
- Flame rating
- FT2
Typical value
Typical value
Typical value
Typical value
| Property | Unit | Requirement | Typical | Test Method |
|---|---|---|---|---|
| Density | g/cm³ | 1.46 | 1.45 | UL 1581 |
| Tensile strength | MPa | ≥ 10.3 | 10.5 | UL 1581 |
| Elongation at break | % | ≥ 150 | 200 | UL 1581 |
| Thermal aging | °C × h | 158 × 168 | 158 × 168 | UL 1581 |
| Tensile strength retention after aging | % | ≥ 80 | 86 | UL 1581 |
| Elongation retention after aging | % | ≥ 80 | 90 | UL 1581 |
| Brittleness temperature | °C | < −40 | < −40 | GB/T 5470 |
| Flame rating | — | FT2 | FT2 | UL 1581 |
| Volume resistivity (20°C) | Ω·cm | ≥ 1.0×10¹² | 3.0×10¹⁴ | GB/T 1410 |
* Typical values are measured on production samples and provided for reference only — they are not a specification guarantee. Request the official TDS for binding limits.
Application & process
Connect the product data to production
Application requirements and processing conditions are reviewed together before sample approval and production supply.
Use cases
Documented applications
- 01Wire and cable insulation and jackets
- 02Automotive wire and thin-wall vehicle wire
- 03Building and installation wire
- 04Power, control and signal cable
- 05Marine cable
Process notes
Processing recommendations
- 01Cross-linkable 125°C polyolefin — confirm the irradiation dose and cross-linking route with our engineers before line trials
- 02Runs on standard LSZH cable extrusion equipment; a halogen-free screw is recommended
- 03Request the full TDS and processing card before mass production
