HZD2820-G
HZD2820-G is a high flame-retardant 150°C irradiation cross-linked LSZH compound — VW-1 capable for rail transit, marine and high-temperature safety cable.
Orange cable compound pellet sample
01 / 02Material — High flame-retardant irradiation cross-linked LSZH compound
Overview
HZD2820-G is a 150°C halogen-free cable compound with a reinforced flame-retardant package (oxygen index 42 typical), colorable, built on a polyolefin base with inorganic flame retardants, antioxidants and lubricants. It serves electronic equipment wire and metro cable insulation where both sustained heat and fire safety matter.
Used as both insulation and jacket in a properly designed construction, cable made from HZD2820-G passes the UL VW-1 vertical flame test, with thermal aging verified at 180°C × 168 h.
Packaging & Storage
Supplied in aluminum-plastic bags with kraft paper lining, 25 kg net per bag. Store in a dry, well-ventilated warehouse.
- Product family
- Materials
- Reference
- HZD2820-G
- Applications
- 4 documented
- Published data
- 17 rows
Grade qualification
Validate the grade against the cable, process and target standard
Published properties establish the review baseline. Cable construction, processing conditions and a line trial complete the grade decision.
- 01
Define the duty profile
Confirm cable construction, operating temperature, flame class and environmental requirements.
- 02
Review the published data
Match requirements, typical values and test methods to the finished-cable target.
- 03
Run a controlled line trial
Set drying, temperature, screw and irradiation conditions from the grade processing card.
- 04
Approve the production window
Record surface, dimensions, mechanical results and finished-cable tests before volume production.
Inquiry input
Send these four details
- 01Cable construction
- 02Target standard
- 03Color and quantity
- 04Extrusion line details
Technical data
Typical Properties
Review requirement, typical production value and test method together. The official TDS defines the binding supply specification.
- Density
- 1.51 g/cm³
- Tensile strength
- 12.31 MPa
- Elongation at break
- 162 %
- Oxygen index
- 42 %
Typical value
Typical value
Typical value
Typical value
| Property | Unit | Requirement | Typical | Test Method |
|---|---|---|---|---|
| Density | g/cm³ | ≤ 1.60 | 1.51 | GB 1033 |
| Tensile strength | MPa | ≥ 10.3 | 12.31 | GB 1040 |
| Elongation at break | % | ≥ 150 | 162 | GB 1040 |
| Thermal aging | °C × h | 180 × 168 | 180 × 168 | GB 2951.7 |
| Tensile strength retention after aging | % | ≥ 70 | 123 | GB 2951.7 |
| Elongation retention after aging | % | ≥ 70 | 82 | GB 2951.7 |
| Volume resistivity (20°C) | Ω·m | ≥ 1×10¹² | 5.35×10¹² | GB 1410 |
| Dielectric strength | MV/m | ≥ 25 | 29 | GB 1408 |
| Oxygen index | % | ≥ 35 | 42 | GB 2406 |
| Flame rating | — | VW-1 | Pass | UL 1581 |
| Smoke density (flaming) | — | ≤ 100 | 83 | GB 8323 |
| Smoke density (non-flaming) | — | ≤ 180 | 135 | GB 8323 |
| Toxicity index | — | ≤ 5 | 1.3 | NES 713 |
| pH | — | ≥ 4.3 | 5.6 | IEC 60754-2 |
| Conductivity | μS/mm | ≤ 10 | 1.2 | IEC 60754-2 |
| Brittleness temperature | °C | < −25 | < −25 | GB 5470 |
| Shore hardness A (D) | — | — | 95 (53) | GB 2411 |
* Typical values are measured on production samples and provided for reference only — they are not a specification guarantee. Request the official TDS for binding limits.
Application & process
Connect the product data to production
Application requirements and processing conditions are reviewed together before sample approval and production supply.
Use cases
Documented applications
- 01Rail transit and metro cable insulation
- 02Marine and shipboard wiring
- 03Electronic equipment wire in hot environments
- 04Jacket and insulation for VW-1 rated cable designs
Process notes
Processing recommendations
- 01Recommended equipment: φ45–150 single-screw extruder, L/D ≥ 20, screen pack 20/80/20 mesh
- 02A dedicated halogen-free screw with compression ratio below 2.5 improves output and surface quality
- 03Temperature profile: feed 110°C / transport 125°C / melting 140°C / die 140–150°C — trim die temperature to wire surface finish
- 04Irradiation dose: 60–100 kGy (6–10 Mrad)
